Ht-225W+ Integrated Digital Concrete Test Hammer
Detailed Product Description Test Range:10~60 MpaImpact Energy:2.207J (0.225kgf.m)Impact Stroke:75mm HT225-W+ is similar as HT225-W, only the powersource is AA battery, more convenient for transportationSpecification:test range: 10~60Mpaimpact energy: 2.207Jspring rigidity: 785N/mimpact stroke: 75mm......
Send Inquiry
Product Description
| Test Range: | 10~60 Mpa | Impact Energy: | 2.207J (0.225kgf.m) |
|---|---|---|---|
| Impact Stroke: | 75mm |
HT225-W+ is similar as HT225-W, only the power
source is AA battery, more convenient for transportation
Specification:
test range: 10~60Mpa
impact energy: 2.207J
spring rigidity: 785N/m
impact stroke: 75mm
difference from scale: <= 0.5
calibration value: 80+/-2
color LCD with 5 level backlight
storage: 300*100*16 test points
in plant with uniform curve, at most 20 special curve
power source: 3.6V/1300mAH lithium battery
battery charger: 5V/2A
last work more than 13 hours without voice service
USB type connection with PC
weight: 1.1kg
HT-225W is an integrated digital concrete test hammer which combines data processor and test hammer into one unit. It is widely used for non destructive testing quality of concrete and building materials in finished structure or prefabricated blocks.
Automatic correction of impact direction
Automatic calculating compressive strength
All testing data can be stored in memory and transferred to PC
